OPK Submarine 9 is a sliding door system for furniture and shelving systems.
Due to its flexible application possibilities, it is also ideal for traditional crafts.
OPK Submarine 9 can also be retrofitted, with no need to make any milling on the cabinet body.
The both sides damping with tumbler is integrated in the running track and thus invisible.
Door hieght |
max. 2200mm |
Door width |
max. 1800mm |
Door thickness |
W≥16mm |
Door weight |
15kg/30kg |
Height adjustment |
±2mm |
Damping |
with both sides |
OPK Submarine 9 is a sliding door system for furniture and shelving systems.
Due to its flexible application possibilities, it is also ideal for traditional crafts.
OPK Submarine 9 can also be retrofitted, with no need to make any milling on the cabinet body.
The both sides damping with tumbler is integrated in the running track and thus invisible.
One for all
Different construction variants possible
Submarine 9, wooden doors thickness 16-25 mm
Easy, fast, tool-free installation, comfortable height adjustment of the fronts
Both sides, invisible damping 15 / 30 kg for minimum installation width and fixable end position
Closure / fixation of the end position possible without damping
Office, kitchen, bathroom
Living, eating, bedroom
Sideboards
Upper and lower cabinets
